ENGINE (designed to instal)

•2.5L Mazda (Duratec) with 30mm restrictor

•Power circa 260 bhp

•Torque circa 220Nm

•Engine (&air box) supplied by the customer

•Stainless steel exhaust, silencer and radiators supplied by Van Diemen

POWERTRAIN

•Six speed (plus 1 R) sequential

•Sadev or Hewland

•Limited slip differential

•Pneumatic Gear change (GCU should bein the ECU as supplied by customer)

•Bespokeadaptor

CHASSIS

•Full Carbon Fibre which complies to F3 FIA 2019 design regulations

•Steel HALO•Fuel tank circa 70L

BODY

•Carbon front, rear lower and upper wings

•Carbon floor

•Glass Fabric engine Cover, fender, side pods

SUSPENSION

•Double Front and Rear Wishbone

•Push Rod and Rockers

•Antiroll Bars Front and Rear

•2 wayadjustable Quantum Damper

•36mm spring

•Upright and Hubs

•Single Nut, Large thread

BRAKING

•AP Callipers•Front CP 9444 4/5)Steel disc 280mm x 18mm

•Rear CP 9445(4/5) Steel disc 280mm x 18mm

•Pads (manufacture TBC)

COCKPIT, DATA & ELECTRONICS

•Aim SW4 Formula Steering Wheel with integral LCD display, paddle shift and multiple on-wheel switching

•Aim Data System

•Sensors including GPS, Water Temperature, Oil Temperature, Oil Pressure, Fuel Pressure, Revs

•Standard wiring loom

SAFETY

•Steel HALO

•Head rest protection

•Side impact structure

•FIA foam filled fuel cell

•FIA fire extinguisher, electronic activation

•FIA collapsible steering column

•Extractable seat

WHEELS & TYRES

•OZ Magnesium centre lock rims

•Front 10” x 13” (tyre size 250/570/R13)

•Rear13” x 13” (tyre size 300/600R13)

•Tyres not included in sale

DIMENSIONS (circa)

•Length4850m

•Width2000mm

•Height1020mm

•WeightTBC
